SPECIFICATIONS
Space: 2.0mm (0.079'') pitch
Pole: 2-16
Applicable wires£ºAWG#22-28
Voltage rating: 250V AC, DC
Current rating: 2A AC, DC
Withstanding voltage: 800V AC/minute
Insulation resistance: 1000M¦¸ min.
Temperature range: -25¡æ to+85¡æ£¨Including temperature rise in applying electrical current£©
Applicable PC board thickness: 0.8mm-1.6mm (0.031''-0.063'')
Contact resistance: Initial value/10m¦¸ max.
After environmental testing/20m¦¸ max
